 Product Name:Lubricating Grease Reactor
Product detail:


Pressure Grease-making Reactor:

    1. Uses:
    It is mainly used to complete the saponification reaction in the process of grease preparation,and can also be used in petroleum, chemical, pharmaceutical and other industries.

    2. Main features:
(1) The planetary type stirring, automatic scraping , uniform mixing, and complete reaction.
(2)The machine uses the heat transfer oil to heat,which is energy saving, environmental protection, security and so on.
(3)The machine uses the advanced mechanical sealing, which is high pressure, leak-free sealing.
   3. Main technical parameters:

Type
Capacity
(L)
Inside Pot Diameter
Jacket Diameter
Motor Power
Output Rotation Speed
Net Weight
     (kg)
1600L
1600
1200mm
1300mm
11 15kw
42r/min
3000
2500L
2500
1400mm
1500mm
15  22kw
42r/min
4120



    Harmonic Reactor:
    1. Uses:
    It is mainly used to complete the harmonic reaction in the process of grease preparation,and can also be used in petroleum, chemical, pharmaceutical and other industries.
    2. Main features:
(1)The planetary type stirring, automatic scraping , uniform mixing, and complete reaction.
(2)The machine uses the heat transfer oil to heat,which is energy saving, environmental protection, security and so on.
(3)The machine uses the advanced mechanical sealing, which is easy to operate.
    3. Main technical parameters:

Type
Capacity
(L)
Inside Pot Diameter
Jacket Diameter
Motor Power
Output Rotation Speed
Net  Weight
(kg)
2500L
2500
1400mm
1500mm
15  22kw
42r/min
3600
4000L
4000
1600mm
1700mm
18.
5 30kw
42r/min
5500



    Auxiliary  Equipments:

    The machine consists of the static shear device, removing gas cylinders, pipe filters, cooling mixer, homogenizer and the racking machine.
